| Technical Specifications | |
| Rated battery energy | 7.68kWh |
| Rated battery voltage | 25.6Vdc |
| Rated battery capacity | 300Ah |
| Output Power | 3600W |
| Output Voltage | 120Vdc±5% |
| Output frequency | 50Hz/60Hz |
| Input voltage range | (90Vac~140Vac)±2% |
| Mains charging current | DC 40A MAX |
| Loaded motor capability | 2HP |
| PV Max. Open-Circuit Voltage | 300Vdc |
| PV operating voltage range | 120Vdc~300Vdc |
| Maximum PV input power | 4500W |
| Maximum PV input current | 27A |
| PV charging current | DC 80 MAX |
| Hybrid charging current | DC 80 MAX |
| Cycle life | 6000+ |
| Product size | 508*308*525mm |
| Net Weight | ≈68Kg |
