| Technical Specifications | |
| Rated battery energy | 20kWh |
| Rated battery voltage | 51.2Vdc |
| Rated battery capacity | 392Ah |
| Output Power | 12000W |
| Output Voltage | 230Vdc±5% |
| Output frequency | 50Hz/60Hz |
| Input voltage range | (170Vac~280Vac)±2%@UPS Mod (90Vac~280Vac)±2%@APL Mode |
| Mains charging current | DC 150A MAX |
| Loaded motor capability | 8HP |
| PV Max. Open-Circuit Voltage | 500Vdc |
| PV operating voltage range | 120Vdc~500Vdc |
| Maximum PV input power | 9000W+9000W |
| Maximum PV input current | 27A+27A |
| PV charging current | DC 150 MAX |
| Hybrid charging current | DC 150 MAX |
| Cycle life | 6000+ |
| Product size | 715*435*1050mm |
| Net Weight | ≈215Kg |
